Dot Matrix LED 8×8 is an array of LEDs that you can display particular numbers, letters, and shapes on it. Dot matrixes are indicated by the number of rows and columns. The most popular type of Dot Matrix is its 8×8 type, which provides 64 LEDs in 8 rows and 8 columns.
- Feb 14, 2017 This is a very easy project for starters like me, the idea of it is to show you how to send bytes to an 8x8 LED matrix. In that link you will be able to make more shapes. In the left hand part of the page there will be an 8x8 matrix, with all the Leds off, by clicking them they will turn on and at.
- Led matrix interfacing with pic microcontroller: A dot matrix Led display is a 2-dimensional patterned array of LEDs, used to represent characters, symbols and images. It can be used in simple display applications where the resolution is not a big concern.In this tutorial we will learn how to interface Dot matrix LED display with pic microcontroll.
LED Matrix
Buy Now
- 3Interfacing Dot Matrix Display with Arduino UNO
Introduction
A Dot-Matrix Display is a display device which contains light emitting diodes aligned in the form of matrix.This Dot matrix displays are used in applications where Symbol, Graphic, Characters, Alphabets, Numerals are need to be displayed together in static as well as Scrolling motion.Dot Matrix Display is manufactured in various dimensions like 5x7,8x8,16x8,128x16, 128x32 and 128x64 where the numbers represent LED's in rows and columns, respectively.Also these displays comes in different colors such as Red, Green, Yellow, Blue, Orange, White.
Working of Dot Matrix Display
In Dot matrix display,multiple LED's are wired together in rows and columns,in order to minimize the number of pins required to drive them.The matrix pattern is made either in row anode-column cathode or row cathode-column anode pattern.In row anode-column cathode pattern, the entire row is anode while all columns serve as cathode which is shown below and it is vice-versa in row cathode-column anode pattern.
In a 8×8 matrix,the LED's would need 64 I/O pins, one for each LED pixel. By wiring all the anodes together in rows (R1 through R8), and cathodes in columns (C1 through C8), the required number of I/O pins is reduced to 16. Each LED is addressed by its row and column number.Characters can be displayed by fast scanning of either rows or columns.To display a character,the row and column pins should be pulled low and high according to that character.For example,the row and column pins should be enabled as per the table given below to display a character 'M' in which the red marks denotes that led is on.
Interfacing Dot Matrix Display with Arduino UNO
Hardware and Software Required
- Dot Matrix LED Display(8x8)
- MAX7219 IC
- Arduino UNO
- Arduino IDE 1.0.6 Version
How to interface Dot Matrix Led Display with Arduino UNO
Before interfacing Dot matrix with Arduino,we need to connect the Max7219 IC which is an Led driver to the Dot matrix display.The reason behind using this led driver is that it drives the 64 Led's simultaneously which in turn reduces the number of wires so that the user will find it easy to connect the display to the Arduino board.
The MAX7219 has four wire SPI interface(we need only this four wires to interface it to the Arduino board):
- Data - MOSI - Master Output Serial Input.
- Chip select - Load (CS) - active low Chip select.
- Clock - SCK(max 10MHz)
- Ground.
Now,the Dot matrix display could be connected to the Arduino board as follows:
- DIN is connected to Digital pin 8
- CS is connected to Digital pin 9
- CLK is connected to Digital pin 10
- Vcc and Gnd to 5V and Gnd
Program to Turn On the Led
Dmg Dot Matrix Pattern On Display Screen
The program given below is an example to turn On and Off the Led at each row and column.The user can download the library file along with few built-in examples here:File:LedControlMS.zip
